AERIAL SURVEILLANCE SYSTEM
ANNOUNCING!
THELATEST AND MOST UNIQUE NEW
AERIAL SURVEILLANCE SYSTEM

...CONSISTING OF A MINIATURE REMOTELY CONTROLLED
AERIAL SURVEILLANCE VEHICLE !
...EQUIPPED WITH A WIRELESS MICRO CAMERA (W/  AUDIO),
PLUS  AN ENTIRE SELF-CONTAINED 'BACKROOM OPERATION'!

...The 'BACKROOM OPERATION - FROM THE BRIEFCASE' which
is  COMPLETELY integrated within a Custom Designed Case
…and which OFFERS:
3 MONITORING / RECORDING METHODS with INTERNALLY
CONNECTED - and SELF-POWERED COMPONENTS:
  From the Creators of Aerial Surveillance in a Briefcase…

…HERE IS THE SYSTEM THAT OFFERS SOMETHING NEVER SEEN BEFORE!!!

(And it is best viewed on a Monitor with a Minimum of 800 X 600 Pixels Resolution)

The system that also offers methods and applications that have not been done before … nor were they possible … before the introduction of the 'ASV-1' - theMiniature Remotely Controlled

AERIAL SURVEILLANCE VEHICLE !




TAKE ADVANTAGE OF ALL THE EXCEPTIONAL BENEFITS THAT OUR UNIQUE NEW
AERIAL SURVEILLANCE SYSTEMOFFERS
YOU - TO HELP PREVENT CRIME, TRAGEDIES, OR TERRORISM!

ALSO, MINIMIZE DAMAGE, SAVE LIVES AND PROPERTY, FACILITATE CRIMINALS CAPTURE, SPEED-UP  SEARCH, RESCUE, RECOVERY, etc. - BY GAININGTHE VISUAL ADVANTAGE THAT OUR SYSTEM WILL PROVIDE YOU!


 APPLICATIONS:

1. APPLICATIONS WITH THE USE OF OUR

    AERIAL SURVEILLANCE VEHICLE !

    THE USE OF OUR AERIAL SURVEILLANCE VEHICLE !
    OFFERS AN ABSOLUTELY INCOMPARABLE NEW METHOD OF
    GAINING A CLOSE-UP VISUAL ACCESS, AND MONITORING, IN UP TO
    NOW MOSTLY INACCESSIBLE PLACES…. AND THUS IT CAN ALSO
    POTENTIALLY SAVE LIVES AND INJURIES.

    'FLY-IT-IN', WITH CONFIDENCE, INTO SERVICE IN ANY OF THE FOLLOWING AREAS:

    LAW ENFORCEMENT
      SAFE VIEWING OF DANGEROUS / UNPREDICTABLE SUSPECTS
      FOLLOW / MONITOR STATIONARY OR SLOW MOVING VEHICLES
      MONITOR UNCOOPERATING / BARRICADED SUSPECTS
      UNDERCOVER SURVEILLANCE / CRIME FIGHTING
      VIEW & MONITOR UNRULY CROWDS, DEMONSTRATIONS, RIOTS
      'SWAT TEAM' SITUATIONS ( METAL BLADES /  'WEAPONIZED VERSION'- ON REQUEST)*
      SPOOK / DISTRACT / INJURE (BLADES) HOSTAGE TAKER TO CAPTURE HIM

    SEARCH AND RESCUE
      VIEW INTO HIGH FLOORS / WINDOWS
      VIEW OVER HIGH FENCES & WALLED COURTYARDS
      VIEW INTO COLLAPSED / BURNED BUILDINGS
      VIEW OVER UNSAFE ROOFTOPS / BALCONIES

    INACCESSIBLE TERRAIN
      STEEP HILLS / DEEP RAVINES, CAVE OPENINGS
      UNPENETRABLE BARRICADES / BARBED WIRE
      TRUCK AND BUS DEPOTS / TRAIN YARDS / MARINAS

    DANGEROUS LOCATIONS
      BOMBS / EXPLOSIVES / MINES
      FOREST / STRUCTURE FIRES
      UNSAFE / DAMAGED BUILDINGS
      HAZARDOUS / TOXIC MATERIALS
    DISASTER AREAS / CRASH SITES
    WILD ANIMALS

    COVERT SURVEILLANCE
    Use the unique versatility of our 'almost invisible' and 'almost silent'
    AERIAL SURVEILLANCE VEHICLE !(from as close as approximately
    50 feet away!) to accomplish the tasks that up to now were not even imaginable!

    AERIAL VIDEOGRAPHY
      DO NOT spend a small fortune to fly an Airplane or a Helicopter for your
    Aerial Photography assignments  … if you can do the same by flying-in our
    AERIAL SURVEILLANCE VEHICLE !… and use it for any type of
    Aerial shots … even your 'PAPARAZZI' projects, at the fraction of the cost!

    So, if it is not fit or feasible for humans, dogs, robots, or
    stationary cameras, use the unique versatility of our
    AERIAL SURVEILLANCE VEHICLE!
    …and see AND dowhat you COULD NOT see AND do before!

    To best demonstrate its nimble flying characteristics, there is a series of 'Still
    Shots' - which depict the incredible flyingprecision of the
    AERIAL SURVEILLANCE VEHICLE !!
    These are taken from a Video created during a flight in one of the Natural History Museums in the USA!

    They can be viewed by clicking here!

    Also, to best demonstrate its capabilities and performance, and 'some of the
    results' of theAERIAL SURVEILLANCE VEHICLE !
    and the Video shot by its On-board Camera, there is another series of 'Still
    Shots' - which depict what its On-board Camera did 'see'!...

    They can be viewed by clicking here!

    Although this Application for a close-up examination of the
    Dinosaur's teeth, and Pterosaur's beak, is NOT the reason for
    which theAERIAL SURVEILLANCE VEHICLE !
    was created, it is the best demonstration of its endless
    uses ... for which the imagination is the only limit!

So, look over the pictures on those pages and think of all the ways you can make our
AERIAL SURVEILLANCE VEHICLE !work for you!
2. APPLICATIONS WITHOUT THE USE OF OUR AERIAL SURVEILLANCE VEHICLE ! THE USE OF OUR WIRELESS MICRO CAMERABY ITSELF ALSO OFFERS AN INCOMPARABLE NEW METHOD OF GAINING A CLOSE-UP VISUAL ACCESS, AND MONITORING, (W/ AUDIO) IN A VARIETY OF UNTIL NOWUNACHIEVABLE UNDERCOVER SURVEILLANCE SITUATIONS!
  ‘SUPER MICRO’ SIZE   ITS SIZE MAKES IT EXTREMELY CONCEAL ABLE
  IT ALSO MAKES IT EASILY FIT IN THE SMALLEST OF PLACES ‘ULTRA LIGHT’ WEIGHT   ITS WEIGHT MAKES IT EXTREMELY ‘WEARABLE’
  IT ALSO MAKES IT EASILY WORN WITHIN THE CLOTHING
  … AND DISGUISEABLE WITHIN SMALL PERSONAL ITEMS
  AND SO MANY PLACES TO HIDE IT IN!… VERY LOW POWER CONSUMPTION   LONG LASTING AND RELIABLE!
  2-4 HRS WITH A 9V BATTERY
  8-10 HRS WITH THE INCLUDED 6V (4 X 1.5V) BATTERY PACK
So, if your Surveillance Activities require the smallest, most
concealable Wireless Micro Camera – use our unique
Multipurpose model which will let you see what you need to see !


3 MONITORING METHODS:
 DESIGNED FOR THE ULTIMATE MONITORING AND RECORDING VERSATILITY
    1.
    The VIDEO and AUDIO Outputs from the Micro Camera's 2.4GH RECEIVER,(whichis also housed and powered from within the Carrying Case) are fed directly into the 5 Inch LCD MONITOR with Audio/Video capability! The LCD MONITOR is a 'Flip-Up' type and is conveniently located in the front part of Carrying Case, so that with its Adjustable Viewing Angle it makes for very easy viewing.


    2.
    That same VIDEO and AUDIO Outputs are simultaneously available - via the provided high quality Audio & Video cables - for external recording on any VCR or any Video CAMCORDER capable of recording from EXTERNAL INPUT (Such as SONY HANDYCAM Models CCD-TRV 75, 85, 93, 715, 815, and similar Models from Sony or other Brands)…

    3.
    Also included is the separate Hardware / Software Interface which takes the same VIDEO and AUDIO Output from the 2.4GH RECEIVER, and converts it into the signal which is then fed via the CONVERTER's own 6 foot cable - with an USB connector - directly into the (Notebook) Computer USB Port. This enables the VIDEO Digital Recording on the NOTEBOOK Computer Hard drive (using the supplied software). In addition, Windows own 'Movie Maker' Application can be used for the same VIDEO Recording / Playing tasks.

POWER SOURCES:

The entire System is powered with a single 12VDC Cigarette Lighter Connector (with an easy retractable cord!), which through internal connections supplies power (via an 'Y' splitter) to the major components in the Carrying Case:

    A) RECEIVER
    B) MONITOR (Plus any of 2 RECORDING DEVICES: VCR or USB ADAPTER)
    C) BATTERY CHARGER
…so that if it is not used as a source of 'Monitoring Power' when flying the
AERIAL SURVEILLANCE VEHICLE !  its battery as well as that of the
Remote Control can be 'passively prepared' (CHARGED!) for the next use.

The Power Input for this single 12VDC Cigarette Lighter connector also allows for a choice  from the following Power Sources:

    1. FROM VEHICLE'S CIGARETTE LIGHTER / 12VDC POWER REGULATOR
    2. FROM 120VAC / 12VDC CIGARETTE LIGHTER ADAPTER / POWER SOURCE
    3. 12V / 2200mAH 'MAIN' BATTERY (Housed in the Carrying Case)
    4. 15VDC RECHARGEABLE BATTERY (FOR ASV-1)*
*In case that theAERIAL SURVEILLANCE VEHICLE!is NOT in use, even its own 15VDC rechargeable battery is usable as a secondary source, for powering of the Video Receiver and Monitor, as a backup Power Source  (for extravehicular monitoring purposes - when out of reach of the vehicle's cigarette lighter!)…


SYSTEM COMPONENT LIST:

  MAJOR ITEMS
ASV-1 AERIAL SURVEILLANCE VEHICLE (UPPER TRAY)
MICRO WIRELESS CAMERA W/ TRANSMITTER
REMOTE CONTROL / TRANSMITTER UNIT FOR ASV-1
15V RECHARGEABLE BATTERY PACK (FOR ASV-1)
2.4GH VIDEO / AUDIO RECEIVER
5 INCH LCD COLOR VIDEO / AUDIO MONITOR
5 INCH LCD COLOR VIDEO / AUDIO MONITOR
VIDEO / AUDIO USB PORT (Notebook) COMPUTER INTERFACE ADAPTER
  DIGITAL VIDEO RECORDING VIA USB ADAPTER SOFTWARE (CD ROM)
  15VDC BATTERY CHARGER (For ASV and Remote Control Batteries)
120VAC POWER ADAPTER FOR RECEIVER
120VAC POWER ADAPTER FOR CAMERA
120VAC TO 12VDC CIGARETTE LIGHTER ADAPTER / POWER SOURCE
12VDC REGULATED CIG. LIGHTER ADAPTER (WIRED AS PRIME POWER SOURCE)
12V / 2200mAH RECHARGEABLE BATTERY - (WIRED AS ALTERNATE SOURCE)
6VDC (4 X 1.5 'AA') BATTERY PACK FOR CAMERA (WITH SWITCH AND CABLE)
BELT CLIP ASSEMBLY FOR CAMERA BATTERY PACK

 TO VIEW THESE COMPONENTS, CLICK HERE!
 Note: The contents and the specifications are subject to change without notice!
SYSTEM HIGHLIGHTS:

The most important component of the entire SYSTEM is the newly developed

AERIAL SURVEILLANCE VEHICLE !

It features some of the most amazing flying characteristicsin its role as an ‘almost’ invisible and silent precision flying / floating / ‘targeted landing’ platform for the Wireless Camera … and its power source…

This revolutionaryAERIAL SURVEILLANCE VEHICLE !is the latest tool that will find its place not only in the arsenal of the Law Enforcement, Search & Rescue, and Surveillance Professionals, but also in many other areas such as  Real Estate etc. …not to mention the ‘Paparazzi’ and many other Videographers needing to reach the 'up to now unreachable'…

Its appeal is not limited to the experienced 'flyers' as it is very easy to be controlled (with minimum ‘Training’), and its Carbon Fiber structure can ‘survive’ the ‘crashes’ from the 2nd floor heights – without any damage…

So, with our AERIAL SURVEILLANCE VEHICLE !even the beginners can be fully functional with it in a short time and little practice.!

System Components are firmly packaged and positioned in their custom designed compartments within the sturdy System Case, for the best shock protection from the rough handling and shipping.  However, the System is relatively light in weight, easily portable and provides INSTANT USABILITY - whether for the Flying out of the
AERIAL SURVEILLANCE VEHICLE !- or for just conducting Covert Surveillance ‘from the shirt pocket’!…

 SPECIFICATIONS:

ASV-1 SPECIFICATIONS
FM TRANSMITTER 4- CHANNEL
RADIO OPERATING FREQUENCY 72, MHz
RADIO FREQUENCY RANGE 1/2 MILE
ROTOR DRIVE MECHANISM MOTOR DRIVE GEARS W/ PRECISION BALL BEARINGS
CPU SOLID-STATE PIEZO (3 UNITS)
MOTOR HIGH SPEED MABUCHI ELECTRIC MOTOR (4)
OUTDOOR FLIGHT ENVIRONMENT RECOMMEND LESS THAN 5 MPH WIND VELOCITY
BATTERY LIFE
8 CELLS (9.6VDC) 600mAh NICAD 5 MINS
10 CELLS (12VDC) 600mAh NICAD 8 MINS / 2O MINUTES WITH AN OPTIONAL EXTRA HEAVY DUTY BATTERY! (AVAILABILITY / PRICE TO BE ANNOUNCED IN THE NEAR FUTURE)
AUTO/MOTORCYCLE BATTERY > 1HR WITH 12 FEET TETHER CORD
LOAD CARRYING CAPACITY < 1 OUNCES (WIRELESS MICRO CAMERA)
LEVEL OF DIFFICULTY BEGINNER, NO FLYING EXPERIENCE NEEDED
MATERIALS
MAIN FRAME CARBON FIBER (CRASH / DROP RESISTANT)
BLADES FOAM PRESSED THERMAL PLASTIC ('WEAPONIZED VERSION' - METAL BLADES - ON REQUEST ONLY)
DIMENSIONS
HORIZONTAL 28" ROTOR TIP TO ROTOR TIP
VERTICAL (HEIGHT) 7"
BLADES (WIDTH) 11"
CURRENT DRAW 7 AMPS
WEIGHT APPROX. 17 OUNCES WITH 8 CELLS BATTERY

COLOR MICRO CAMERA SPECIFICATIONS
SENSOR FORMAT 2ND GENERATION CMOS
PIXELS 364K (PAL), 250K (NTSC)
RESOLUTION 380 TV LINES
AUTO ELECTRONIC EXPOSURE 1/60 - 1/5,000 SEC.
AUTO EXPOSURE/GAIN/WHITE BALANCE
MIN. ILLUMINATION 1 LUX @ F1.2
S/N RATIO 48dB
AUDIO CONDENSED AMPLIFIED MIC.
BROAD LENS 5.6mm
FIELD ANGLES 60 DEGREES
OTHER LENS FORMAT (OPTION) 2.1, 2.5, 2.9, 3.6 4.3, 6.0, 8.0, 12.0, 16.0 mm

2.4 GHZ A/V TRANSMITTER SPECIFICATIONS
4 CHANNELS (AVAILABLE) 2.412, 2.432, 2.452, 2.472 (GHZ)
RF OUTPUT POWER FCC COMPLIANT 10mW
OPERATING POWER 4.8 - 7.2 V (REGULATED)
POWER CONSUMPTION 10 mA
SIZE 18X34X20mm
WEIGHT 0.4 OZ WITH CAMERA
ANTENNA OMNI-DIRECTIONAL ANTENNA
TRANSMITTING RANGE 300 M L.O.S.
TEMPERATURE RANGE -10 TO +50 DEGREE C

2.4 GHZ A/V RECEIVER SPECIFICATIONS
4 CHANNELS (SELECTABLE) (MANUAL SWITCH) 2.412, 2.432, 2.452, 2.472 (GHZ)
VIDEO OUTPUT 1V P-P / 75 OHMS
AUDIO OUTPUT 0.8V/ 600 OHMS
ANTENNA 60 DEGREE DIRECTIONAL ANTENNA
AUDIO BANDWIDTH 50-17,00 HZ
OPERATING POWER DC12V REGULATED
SIZE 150X88X40mm

Note: Specifications on all other 'off-the-shelf' components used in the system are subject to frequent changes and are not included in this list!

FOR PRICING AND OTHER INFO PLEASE CALL: 714/444-2424, EXT. 17
